Page 23 - Westform Product Catalogue July 2025 Public

Recommended flashings Roof flashings will be 4/12 pitch unless
otherwise specified
wall base BENT AT 5 SLOPE HEADER BENT AT 5 SLOPE STARTER BOX WALL TRANSITION
0
0
1236DC 1236HD COLOR 2 SIDE 1236SB 1236WT
2-1/2”
3-1/2” 3” 1-1/2” 3-1/8”
1-1/2” 1-3/8”
1-1/2” 1-1/2”
1/2” 1/2” 1” 1”

1/2” 6” 1/2” 1-1/2” 9” 1-1/2” 1/2” 9” 1/2” 6”
J TRIM 1 COLOR 1 SIDE J TRIM 2 COLOR 2 SIDE o/s corner post I/S CORNER POST 1236ICP
1236JT1 1236JT2 1236OCP 2-1/2” 1” 1” 1-3/8”
2-1/2” 1-3/8”
2-3/4” 1” 1-3/8” 1-3/8” 1”
3-1/8”
1/2” 1”
1” 1” 1-3/8”
2-3/8”
1” 3-1/2” 2-1/2”
1-3/8” 6” 1-3/8” 9” 3-1/2” 18” 2-3/8” 12”

Galv / lume smp pvdf/TEX Galv / lume SMP PVDF/printech/TEX
width
26 gauge 26 gauge 26 gauge 24 gauge 24 gauge 24 gauge
4”
6”
9”
12”
15”
18”
24”
30”
36”
terms net 30 days. prices subject to change without notice.
