Page 79 - Westform Product Catalogue July 2025 Public

skylite flashings

skylite pan 1a skylite pan 1b skylite pan 1C
A = 2x4 curb height B = 2x6 curb height C = 2x8 curb height
SKY1A SKY1B SKY1C

3-1/2” 5-1/2” 7-1/2”
14-1/2” 12-1/2” 16-1/2”

18” 18” 24”

skylite 2-a, b, c skylite 2-a, b, c skylite 2-a, b, c
weathershield DURACLAD/ALLCLAD/DIAMOND WF-7/8” Corrugated
WSSKY2-A,B,C DCSKY2-A,B,C CORSKY2-A,B,C
A=9” A=9” A=9”
A=3” B=12” A=2-3/4” B=12” A=2-1/2” B=12”
B=5” B=4-3/4” B=4-1/2”
C=7” C=15” C=6-3/4” C=12” C=6-1/2” C=15”
5-1/2” 4-1/2” 6”

1/2” 3/4” 1/2”

skylite 2-a, b, c skylite 2-a, b, c skylite 2-a, b, c
Prolok WF-12-36 WF-636
PRSKY2-A,B,C 1236SKY2-A,B,C 636SKY2-A,B,C
A=9” A=9” A=9”
A=2-1/2” B=12” A=2-1/4” B=12” A=2” B=12”
B=4-1/2” B=4-1/4” B=4”
C=6-1/2” C=15” C=6-1/4” C=15” C=6” C=15”
5-1/2” 5-1/2” 6”

1” 1-1/4” 1/2”

Galv / lume smp Galv / lume smp pvdf/tex Galv / lume smp pvdf/tex aluminum
width
29 gauge 29 gauge 26 gauge 26 gauge 26 gauge 24 gauge 24 gauge 24 gauge 24 gauge
4”
6”
9”
12”
15”
18”
24”
30”
36”
terms net 30 days. prices subject to change without notice.
