Page 117 - Westform Product Catalogue July 2025 Public

KEY-HOLE

SYSTEM

JULY 2025

Estimated Suggested
Drawing Description Shipping Product Retail
Code
Weight Price
http://www.cnbhnp.com/index.php
KEY-HOLE TRACK, 14 Ga. Galv. track. Patented key-hole 643836 8’
design makes this track the most versatile of the track 643837 10’
mounted systems. Keyholes are punched every two feet for 2 lbs. per ft. 711061 12’
mounting brackets. 711063 16’
711065 20’

CEILING BRACKETS, Zinc plated. Permits one or more runs
of track to be mounted to ceilings on overhead supports.
.3 lbs. each 646602

UNIVERSAL SIDE BRACKET, Zinc plated. For use when
mounting a single run of track. Used as an intermediate
support for heavy doors. .9 lbs. each 646505

BOLT HUNG BRACKET, zinc plated. May be used whenever
it is necessary to hang from metal construction on 1/2-13
x 1-1/2” bolt, less nuts. Also works as a splice collar. Lug 3 lbs. each 649017
needs to be knocked out when used as regular bracket.

UNIVERSAL DOUBLE SIDE BRACKET, zinc plated. For
mounting two parallel runs of track. Usually used for by
passing doors. 3 lbs. each 646801

TRACK CURVE, 90 with 38” radius, three 646505 brackets
0
welded in place. For use when desired door width exceeds
two times wall length. Can be used with Bracketrack, Key- 15 lbs. each 643312
hole or Tubular track systems. Zinc plated.

SPLICE COLLAR, galvanized with locking lugs to hold track
firmly in place and keep from rotating. One required for
each section of track less one. .6 lbs. each 465101

END CAPS, packaged per pair with mounting bolts in a
plastic bag.
.6 lbs. each 711489

TERMS Net 30 Days. Prices subject to change without notice. Page 5
