Page 118 - Westform Product Catalogue July 2025 Public

KEY-HOLE

SYSTEM

JULY 2025

Estimated Product Suggested
Drawing Description Shipping Code Retail
Weight Price
http://www.cnbhnp.com/index.php
BIGG FRAME-FACE MT BRACKET FOR TRACK AND COVER:
May be used on 1” or 2” track plank. Galvanized for doors
up to 4-3/4” thick. Especially suited for Cannonball: HNP 4 lbs. each 710808
Bigg Frame System. 646224 or 646225 can be used with
this bracket. See Cannonball installation manual.
FACE-MOUNT BRACKETS FOR TRACK AND COVER. May be
used on 1” or 2” track plank. Galvanized, for doors up to
3-3/4” in thickness. .4 lbs. each 646513

See Cannonball installation manual.

WHITE-FACE MOUNT TRACK COVER. Used in conjunction
with Face-Mount Brackets 646513 on 2” track plank (Stock
colors also available). 8 lbs. each 646225 10’

WHITE-FACE MOUNT TRACK COVER END TRIM. Bird proofs
the space between the track and cover and serves to finish
off the cover ends. Matches track cover 646225. Packaged .6 lbs. each 711210
per pair with screws in a plastic bag(white).

TOP-MOUNT KEY-HOLE BRACKET FOR TRACK AND COVER.
May be used on 2” track plank only. Galvanized, for doors
up to 3-3/4” in thickness. .3 lbs. each 646519
See Cannonball installation manual.
WHITE TOP-MOUNT TRACK COVER. Used in conjunction
with top-mount bracket 646519 (Stock colors also
available). 8 lbs. each 646226 10’

TOP-MOUNT WHITE COVER END TRIM. Bird proofs the
space between the track and cover and serves to finish off
the cover ends. Matches 646226 track cover. Packaged per 1.2 lbs. each 711212
pair with screws in a plastic bag(white).

FACE-MOUNT BRACKETS FOR TRACK ONLY. Used where
track cover is not required, such as indoor applications.
May be used on 1” or 2” track plank. Galvanized brackets. .2 lbs. each 646512

TERMS Net 30 Days. Prices subject to change without notice. Page 6
